Safegard Systems controls upgrade is boost for fire safety

Safegard Systems has responded to growing demand from building owners, facility managers and emergency services for more flexible operation and testing of fire and smoke dampers by significantly upgrading its controls packages. Safegard Systems, which is part of Swegon has updated its widely used damper control system and is working directly with consulting engineers and contractors to provide specific fire and smoke control design expertise.

In the event of a fire, the dampers should close immediately to prevent the spread of fire and smoke through the ducting or open when needed to enable smoke extraction. The way they are controlled plays a vital role in keeping escape routes clear and allowing access for fire-fighters.

Safegards fifth generation V5 addressable life safety system is a flexible and sophisticated package, designed specifically for the control of smoke and fire dampers. Unlike most fire alarm systems, a dedicated panel can monitor damper end switches and does not assume that, simply because power has been removed, the dampers have reached a failsafe position.

The system has been updated to add several important new features to its widely used predecessor, which already provided the ability to manage multiple dampers from a single simple interface without the need for additional hardware. Safegard Systems believes this is critical for the safety of buildings and can also provide lifetime cost savings for building owners.


The V5 employs a solid-state embedded computer for reliability and is simple to use and install. It is based around a two-core network cable that communicates with the local interfaces at each damper. This significantly reduces wiring costs compared to more conventional hard-wired solutions.

Heat and smoke detectors can be fitted directly into the damper interface, either to control the damper to which it is fitted or other dampers within the system. It can also be linked to a local test switch enabling dampers to be conveniently and easily tested remotely or via the test function available at the panel. The system can also be scheduled to automatically test dampers on a regular basis and provides remote access for checking and maintenance.

The V5 is designed to work on interoperable open protocol platforms and can also be linked to the building management system (BMS) via RS485 or BACnet. This open system approach provides considerable lifecycle benefits to the end client for ongoing operation and maintenance.

he control system consists of a 15-inch embedded panel computer, UPS and pre-loaded software, which is extremely user friendly. The server architecture reduces commissioning time, simplifies operation and allows scope for future changes to the building and its HVAC systems. It also provides full diagnostics for system and device integration.

In many cases the fire alarm system is used to control dampers, but this strategy does not offer the flexible and sophisticated operation that is built into the V5 system. More basic approaches simply shut every damper in the building in the event of a fire whereas the V5 offers control of each individual damper. This allows system designers to provide users with a more strategic and targeted approach for fire compartmentalisation, pressurisation and smoke extraction.

“There is growing awareness across the Irish building sector of the need to provide a more flexible and sophisticated approach to fire and smoke control,” said Stephen Martin, Head of Sales & Marketing at Safegard Systems.

“As a result, more people are looking for expert advice and tailor-made solutions that fit their fire safety strategies. They want a sophisticated approach, but one that is also easy to use – and works quickly and automatically in the event of a fire to support the emergency services. The Grenfell Tower inquiry has clearly exposed the inherent dangers in simply looking for the cheapest solutions. It never makes sense to cut corners when it comes to fire safety and using a purposely designed product for life safety damper control provides peace of mind. However, it can also deliver major cost savings over the lifecycle of the building by cutting maintenance costs and easing access,” added Mr Martin.
